Barcode Scan Engines for Retail and Hospitality Applications

The Opticon barcode scan engine product family is comprehensive, offering the best options to accommodate your specific solution and budget needs. Our team of experts provide support through every phase of the product development process, even down to pre-sales engineering support.

Applications

  • Retail Point-of-Sale
  • Mobile Data Collection Devices
  • Self-Service Kiosk
  • Self-Service Ticketing
Talk To Us

Featured Barcode Scan Engine Products

MDC-200, 1D CCD

CCD linear sensor (1,500 pixels) barcode scan engine with integrated decoder.

  • CCD linear sensor (1,500 pixels) barcode scan engine with integrated decoder
  • Two models: MDC-100 and the smaller form factor, MDC-200 (7.5mm vs. 11.5mm)
  • Superior scanning performance at 300 scans/second
  • Able to quickly scan 1D barcodes off cell phone displays
  • All solid-state design with no moving parts equates to better MTBF
  • No CDRH requirements and no warning labels needed
  • Small form factor at just 0.90" x 0.45" x 0.59" (WxHxD) and weight of only 0.12 ounces

MDL-1500, 1D Laser

Features a 650 nm visible laser diode that scans bi-directionally at 100 scans/second.

  • Features a 650 nm visible laser diode that scans bi-directionally at 100 scans/second
  • Complete barcode scan engine module with integrated decoder
  • Perfect for integration into small, space-constrained mobile, medical or retail barcode scanning devices
  • Small size makes it easy to mount
  • Programmable software with a wide variety of options
  • Low power consumption to fit your design needs
  • Communication: Serial CMOS - 12 pin FFC connector, USB-HID, USB-COM
  • Engineering kit available—enables faster time to market

MDI-4100, 2D Imager

Industry’s thinnest (10mm) 2D imager barcode scan engine.

  • Industry’s thinnest (10mm) 2D imager barcode scan engine
  • Perfect for integration into small, space constrained mobile, medical, or retail barcode scanning
  • devices
  • High performance and low power 800MHz CPU and an ultra-fast 100 frames per second (fps) CMOS imager sensor enable high speeding scanning of 1D and 2D barcodes and OCR fonts
  • Fast global shutter technology providing exceptional motion tolerance for moving applications
  • Improved scanning of curved, wide, poorly printed and damaged barcodes
  • Data editing program function captures up to 16 codes on multiple images simultaneously
  • Single line green LED and warm, white LED illumination makes it easy to aim while providing safety and an extended service life

Benefits

2-year warranty icon

2-Year Warranty

Opticon's standard warranty period is two years from the date of purchase.

cost effective icon

Cost Effective

Every project has a budget. We work with you to give you the best solution for yours.

customization icon

Innovative Product Customization

As one of the original pioneers in the barcode industry, we have decades of manufacturing and integration experience, as well as the intellectual property for our own barcode scan engines.

customer support icon

Upfront Pre-Sales Consulting

Our pre-sales engineering support aims to understand your unique application, helps to alleviate engineering concerns, and boosts confidence in your deployment. This service is available to you as a free resource and gives you the assurance you need for your scan engine integration project.

Speak with a barcode scan engine expert about your next project.
