Barcode Scan Engines for Medical Applications

Opticon fully understands the growing demands for healthcare organizations. We work with OEMs to support their healthcare customers with our full line of barcode scan engines for their critical product development needs. From single-point products to fully integrated solutions, Opticon is your go-to expert for OEM barcode scanning solutions.

Applications

Medical Diagnostic Equipment
Mobile Data Collection Devices
Medical Point of Care Equipment
Laboratory Automation Equipment

Talk To Us

Featured Barcode Scan Engine Products

MDC-200, 1D CCD

CCD linear sensor (1,500 pixels) barcode scan engine with integrated decoder.

CCD linear sensor (1,500 pixels) barcode scan engine with integrated decoder
Two models: MDC-100 and the smaller form factor, MDC-200 (7.5mm vs. 11.5mm)
Superior scanning performance at 300 scans/second
Able to quickly scan 1D barcodes off cell phone displays
All solid-state design with no moving parts equates to better MTBF
No CDRH requirements and no warning labels needed
Small form factor at just 0.90" x 0.45" x 0.59" (WxHxD) and weight of only 0.12 ounces

MDL-1500, 1D Laser

Features a 650 nm visible laser diode that scans bi-directionally at 100 scans/second.

Features a 650 nm visible laser diode that scans bi-directionally at 100 scans/second
Complete barcode scan engine module with integrated decoder
Perfect for integration into small, space-constrained mobile, medical or retail barcode scanning devices
Small size makes it easy to mount
Programmable software with a wide variety of options
Low power consumption to fit your design needs
Communication: Serial CMOS - 12 pin FFC connector, USB-HID, USB-COM
Engineering kit available—enables faster time to market

MDI-4100, 2D Imager

Industry’s thinnest (10mm) 2D imager barcode scan engine.

Industry’s thinnest (10mm) 2D imager barcode scan engine
Perfect for integration into small, space constrained mobile, medical, or retail barcode scanning
High performance and low power 800MHz CPU and an ultra-fast 100 frames per second (fps) CMOS imager sensor enable high speeding scanning of 1D and 2D barcodes and OCR fonts
Fast global shutter technology providing exceptional motion tolerance for moving applications
Improved scanning of curved, wide, poorly printed and damaged barcodes
Data editing program function captures up to 16 codes on multiple images simultaneously
Single line green LED and warm, white LED illumination makes it easy to aim while providing safety and an extended service life

2-Year Warranty

Opticon's standard warranty period is two years from the date of purchase.

Cost Effective

Every project has a budget. We work with you to give you the best solution for yours.

Innovative Product Customization

As one of the original pioneers in the barcode industry, we have decades of manufacturing and integration experience, as well as the intellectual property for our own barcode scan engines.

Upfront Pre-Sales Consulting

Our pre-sales engineering support aims to understand your unique application, helps to alleviate engineering concerns, and boosts confidence in your deployment. This service is available to you as a free resource and gives you the assurance you need for your scan engine integration project.
